Vertical Wood Slat Wall Panels

Vertical Wood Slat Wall Panels

If you are looking for a green sound solution to reduce noise and increase privacy, then acoustic slat wood wall panels may be perfect for you. This type of wall panel is a great choice for areas like bedrooms or living rooms to reduce noise pollution and improve quality of life. At the same time, this panel will not pollute the environment and is very environmentally friendly. If you want to know more, then contact LEEDINGS, we have experts to answer your questions!

Edit

Architectural Linear Rhythm · Floor-to-Ceiling Slat Cladding

Vertical Wood Slat Wall Panels (Akupanel Series)

Natural Wood Veneer · Precision Linear Slats · 9mm Sound-Absorbing Recycled PET Felt

Designed to create continuous vertical lines and spatial height in modern interiors. By pairing real timber warmth with a black acoustic PET felt substrate, our vertical slat panels eliminate flutter echoes (NRC 0.85) while providing seamless full-height floor-to-ceiling installation up to 3 meters.

Factory Direct Procurement · China & Thailand Dual Production
• Thailand factory export bypasses US Section 301 tariffs (0% duty) · Standard 2400/2600/3000mm lengths · Full container wholesale capacity.

Vertical Wood Slat Wall Panels Overview

📏

Vertical Spatial Elongation
Available in 2400mm, 2600mm, and 3000mm single-run lengths to cover floor-to-ceiling heights without horizontal seams or trim breaks.

🔊

Synchronized Acoustics (NRC 0.85)
Dual acoustic control: hard timber slats diffuse sound waves across the room while the porous 9mm PET core absorbs vocal reverberation.

🪵

Architectural Timber Finishes
Grade-A real wood veneers (White Oak, American Walnut, Ash, Teak) protected with durable, non-yellowing UV coating.

🛡️

Commercial Fire & Safety Rating
ASTM E84 Class A fire-rated PET core, FSC® certified wood sourcing, zero formaldehyde off-gassing (E0), and low VOC.

Acoustic Structure & Slat Anatomy

Constructed with a 3-tier composite matrix: authentic real wood veneer bonded to a 12mm high-density black MDF slat core, heat-laminated onto a 9mm flame-retardant recycled polyester felt backing.

Vertical Slat 3-Layer Structure Diagram
Vertical Slat Dimension and Slat Profile

Technical Specifications & Logistics Data

Standard Profiles• LD27-13: 27 mm slat width / 13 mm gap width (Classic Slim Vertical Slat)
• LD35-15: 35 mm slat width / 15 mm gap width (Bold Architectural Slat)
Panel Dimensions• Width: 600 mm (Standard) / 400 mm
• Length: 2400 mm, 2600 mm, 3000 mm, or 1200 mm (Cut-to-size available)
Overall Thickness21 mm (12 mm MDF core slat + 9 mm high-density PET acoustic felt backing)
Acoustic Substrate100% Recyclable Polyester Fiber Felt (ASTM E84 Class A flame-retardant standard)
Slat Core & SurfacesHigh-density moisture-resistant Black MDF Core finished with Natural Wood Veneer, Melamine Laminate, or Technical Veneer
Unit WeightApprox. 7.5 kg / m² (~10.8 kg per standard 2400 × 600 mm panel)
Acoustic PerformanceNRC = 0.85 (Direct Mount or 45mm Batten Cavity, tested per ISO 354 / ASTM C423)
Container Loading Capacity• 20'GP Container: Approx. 1,000 m² (~690 panels)
• 40'GP Container: Approx. 2,500 m² (~1,730 panels)
• 40'HQ Container: Approx. 2,900 m² (~2,000 panels)

Vertical Slat Width Options & Profiles

Select the classic LD27-13 profile for delicate linear texture in residential lounges, or the LD35-15 profile for larger commercial atriums, boardrooms, and high-ceiling lobbies.

Model Options LD35-15 and LD27-13 Vertical Slat Profiles

Installation Guidelines & On-Site Methods

Panels can be cut with standard fine-toothed circular saws and mounted via direct black drywall screws through the felt into studs, or fastened directly onto wood furring battens with insulation for enhanced low-frequency sound dampening.

Vertical Slat Installation Step Banner
Vertical Slat Screwing and Glue Detailing

Available Finishes & Color Palette

Choose from natural timber species (White Oak, American Walnut, Ash, Teak) to contemporary Smoked Oak and Matte Black Melamine. Physical swatch sample boxes available for architectural firms and contractors.

Vertical Wood Slat Panels Available Color Options

Commercial & Residential Projects

Installed across executive offices, luxury hospitality reception areas, auditorium feature walls, and modern home theaters.

Vertical Slat Wall in Commercial Feature Lobby
Commercial Lobby Feature Wall
Vertical Acoustic Slat Paneling in Modern Breakout Lounge
Corporate Breakout Lounge
Vertical Slat Paneling in Conference Hall
Auditorium & Conference Hall

Contractor & Specifier FAQ


Q: Why are 2600mm and 3000mm heights preferred for vertical slat installations?


A: Most commercial and residential ceiling heights range from 2.5m to 3.0m. Using full-length 2600mm or 3000mm panels allows a continuous single vertical run from floor to ceiling, eliminating visible horizontal joints, cutting labor by 40%, and maintaining clean architectural sightlines.

Q: What is the acoustic performance difference between direct mounting and batten mounting?


A: Direct screwing onto drywall achieves an NRC of approximately 0.65–0.70. Installing panels over 45mm timber battens with mineral wool insulation inside the cavity increases the NRC to 0.85–0.95, significantly improving low-frequency sound absorption.

Q: Can US buyers import these vertical slat panels duty-free from your Thailand factory?


A: Yes. All panels produced at our Bangkok facility are accompanied by legitimate Certificates of Origin (COO), completely exempting shipments from US Section 301 punitive tariffs.

Q: How are side-by-side vertical panels aligned without visible seams?


A: Each panel features an extended 13mm or 15mm felt flap on one side. When neighboring panels are butted together, the flap sits flush behind the adjacent slat, creating a continuous, seamless vertical slat cadence across the entire wall.

Source Factory-Direct Vertical Wood Slat Panels

Contact our sales engineering team for container load calculations, custom height profiling (up to 3m), and Thailand export dispatch schedules.
